1. Product introduction
Semi Automatic Polarimeter adopts photoelectric detection and automatic servo mechanism control, backlit LCD display, clear and intuitive test data, can save three retest results, and calculate the average value, equipped with RS232 interface, can transmit data to PC.
2. Product parameter
Model: | WZZ-2A/2B |
Measuring range: | -45°~+45° |
Minimum reading value: | 0.002° |
Accuracy: | ±(0.01°+measurement value×0.05%) |
Repeatability (maximum deviation): | ≤0.01 degree |
The lowest transmittance of the measurable sample: | 10% |
3. Product feature
1: Built-in Parpaste temperature control, improve accuracy and stability;
2: there are rotation/specific curl/concentration/sugar degree and custom mode;
3: LED cold light source instead of the traditional sodium light lamp and halogen tungsten lamp;
4: Compliance with 21CFR Part 1 audit trail, pharmacopoeia and electronic signature;
5: Support network printing, support data statistical retrieval;
6: Multi-level authority management, authority can be freely configured;
7:10 inch touch color screen, user-friendly operation interface;
8: The system comes with automatic calibration system.
9: Comply with GLP GMP certification.
4. Fields of use
1. Automatic polarimeter is widely used in medicine, food, organic chemical industry and other fields.
2. Agriculture: analysis of ingredients such as agricultural antibiotics, agricultural hormones, microbial pesticides and starch content of agricultural products.
3. Medicine: analysis of antibiotics, vitamins, glucose and other drugs, pharmacological study of Chinese herbal medicine.
4. Food: sugar, monosodium glutamate, soy sauce and other production process control and finished product inspection, food sugar content determination.
5. Petroleum: analysis of mineral oil, monitoring of petroleum fermentation process.
6. Fragrance: analysis of essential oils.
7. Health services: analysis of clinical diabetes in hospitals.
5. Product details
Yuke Semi Automatic Polarimeter has built-in Peltier precise temperature control system, which can meet users' requirements for testing at constant temperature. The built-in automatic calibration program is optional, and the standard automatic calibration tool can be automatically calibrated from -45 degrees to +45 degrees, which fully meets the user's demand for controllable measurement accuracy in daily operation. The multi-level authority management of Yuke automatic polarometer can meet the audit tracking.
