1. Product introduction
It adopts photoelectric detection and automatic servo mechanism control, digital display reading, can measure dark samples; WZZ-2S type can also measure sugar content, and is equipped with RS232 interface, which can transmit data to PC.
2. Product parameter
Model: | WZZ-2S/2SS |
Measuring range: | -45°~+45° -120°Z~+120°Z |
Minimum reading value: | 0.001° 0.01°Z |
Accuracy: | ±(0.01°+measurement value×0.05%) ±(0.03°+measurement value×0.05%) Z |
Repeatability (maximum deviation): | ≤0.002° ± 0.006°Z |
The lowest transmittance of the measurable sample: | 10% |
Dimensions: | 600×320×220mm |
Weight: | 30kg |
3. Product feature
1: Built-in Parpaste temperature control, improve accuracy and stability;
2: there are rotation/specific curl/concentration/sugar degree and custom mode;
3: LED cold light source instead of the traditional sodium light lamp and halogen tungsten lamp;
4: Compliance with 21CFR Part 1 audit trail, pharmacopoeia and electronic signature;
5: Support network printing, support data statistical retrieval;
6: Multi-level authority management, authority can be freely configured;
7:10 inch touch color screen, user-friendly operation interface;
8: The system comes with automatic calibration system.
9: Comply with GLP GMP certification.
4. Fields of use
Polarimeter Test Device is widely used in industrial production, scientific research and teaching departments such as sugar, pharmacy, drug testing, food, spices, monosodium glutamate, chemical industry, petroleum, etc., for laboratory analysis or process quality control.
5. Product details
Polarimeter Test Device is an instrument for measuring the optical rotation of a substance. By measuring the optical rotation of the sample, the concentration, purity, sugar content or content of the sample can be determined. It is widely used in industrial production, scientific research and teaching departments such as sugar, pharmacy, drug testing, food, spices, monosodium glutamate, chemical industry, petroleum, etc., for laboratory analysis or process quality control.
