Innovation points to improve efficiency:

1: You can see whether the sample has bubbles or not;

2: High automation integration, realizing one-key measurement function;

4: Comes with Peltier temperature control.

1. Using the principle of U-tube vibration method, it is suitable for automatic measurement of liquid density

2. Using imported high-speed XFMD chip processing, high sensitivity and accurate data

3. Automatic sampling: Xiongfa special automatic sampling system, automatic quantitative technology, high precision

4. Using self-developed technology to remove residues to ensure no residues in samples

5. Constant temperature control: Adopting self-developed Peltier refrigeration technology, high refrigeration efficiency and environmental protection

6. Wall-free treatment: the liquid will leave residual liquid on the inner wall of the oscillating tube during the flow process, which will affect the measurement accuracy. Therefore, the wall-free treatment on the inner wall of the oscillating tube can avoid residual liquid on the inner wall of the oscillating tube and ensure Improve the accuracy of the instrument.

7. Data storage and transmission: built-in storage chip, can store 80 sets of test data, and can be recalled and deleted

8. Calibration function: Use 20℃ pure water as a standard to calibrate the instrument, which is a function that cannot be achieved by a glass densitometer

Petroleum, diesel, cleaning fluid, lubricating fluid, chemical liquid, flux, crude oil, chemical reagent, stupid, toluene, flavor and fragrance, essential oil,

Density testing in alcohol and beverage industries can convert the concentration for alcohol and sulfuric acid solutions!

Electronic liquid density meter complies with GB/T29617, ISO12185, ASTMD4052/D5002, GB/T29617-2013, GB/T2013-2010, GB23971-2009, GB4747-2009, SH/T0604-2000, SN/T2383-2009, SH/ T0729-2004, ASTMD4052, ASTMD5002, ASTMD1250, ASTMD3505, ISO12185:1996.

After pumping the liquid to be tested into the resonant cylinder sensor, the single-chip microcomputer performs measurement data processing, which is fast and direct, and has high sensitivity. It is composed of double tuning fork density sensor, vibrating tube circuit, temperature measurement circuit, CPU, display, constant temperature bath, liquid inlet pump and control panel.
