1. Melting point detector introduction
Innovation points to improve efficiency:
1: One-key automatic detection function, effectively avoiding human error;
2: PID precise temperature control;
3: The experiment process can be recorded and replayed without missing every detail;
4: Fully comply with the national standard and ISO method for determining the melting point of fats and oils.
2. Melting point detector parameter
Model | YKY80 |
Temperature display range | 0-400℃ |
Temperature control range | RT-400℃ |
Temperature resolution | 0.1℃ |
Heating gradient | 0.1℃-20℃/ minutes |
Cooling rate | Wind cooling |
Temperature accuracy | ±0.2℃(<100℃) ±0.4℃(>100℃) |
Repeatability | Melting point repeatability was±0.1℃at 0.1℃/Min |
Detection method | Fully automatic (compatible with manual) |
Video function | Photo and video |
Data preservation | 600 |
Storage | 16G |
Display method | TFT high-definition true color screen |
Computer interface | USB RS232 network port |
Capillary can be used | OD:1.3mm ID:1.1mm Length:100mm(Single and double opening) OD:4.0mm ID:3.8mm Length:800mm(Large capillary) |
Processing capacity | 3 pcs per batch |
Number of user management | 10 |
Video playback | YES |
User Management | YES |
Power supply | AC 220V 50/60Hz 120W |
Instrument size | 400*280*330mm |
Weight | 4.1kg |
3. Melting point detector feature
Comply with SNT0801.5-2015, GB/T24892-2010, SNT 0801.5-1999, GBT127662008 standards.
4. Fields of use
Melting Point Detector has an important position in the chemical industry and medical research. It is an essential instrument for the production of food, medicine, spices, dyes and other organic crystal substances.
5. Product details
Heating water bath
Adopt platinum temperature sensor, unique water bath heating design, heating rate 0.1-10℃/min. The temperature display range is 0~100℃, the temperature control accuracy is 0.1℃, the response speed is fast, the accuracy is high, and more accurate experimental results can be obtained.
The water bath uses glass tubes to prevent scaling and rust, easy to clean, and extend the life.
After starting, the temperature will be automatically preheated to the initial temperature set by the user.
Professional software
Experimental results can be automatically generated and saved in experimental reports, and can be printed at any time. The experiment process is automatically recorded and saved to the SD card. When the SD card space is insufficient, the user will be prompted to transfer or clear the data.
Users can observe the experiment process at any time through the window in the software, or through video playback, change the playback speed, and better observe the details of the experiment. The software interface is friendly, simple and easy to use, and various parameters are clear at a glance.
