1. Hot stage for microscope introduction
Innovation points to improve efficiency:
1: Closed furnace body to ensure stable temperature;
2: Accurate heating rate 0.1-20.0 steplessly adjustable;
3: Adopt TFT true color touch screen;
4: Up to 20 sets of methods, each set up to 99 paragraphs.
5: The highest temperature reaches 350°C.
2. Hot stage for microscope parameter
Model | YK370 |
temperature range | Room temperature -400℃ |
Heating rate | (0.1-20) ℃/Min |
Temperature resolution | 0.1℃ |
Temperature control accuracy | ±0.3℃ |
Display method | TFT high-definition true color screen |
Data interface | USB / RS232 / SD / Ethernet port |
Glass slide/cover glass specifications | 76*19*1 / 15*15*0.5mm |
Vision | 2mm |
Sample lens working distance | At least 7mm |
X-Y table | Move up to 13mm |
size and weight | 185*85*28mm / 1kg |
User Management | 15 |
Number of method segments | 99 |
Experimental method storage | 20 set |
Save result | 400 pcs |
Optional accessories | Biological microscope, offset microscope (optional) |
3. Hot stage for microscope feature and application
1. Closed furnace body to ensure stable temperature;
2. Precise heating rate 0.1-20.0 poleless adjustable;
3. Adopt TFT true color touch screen;
4. Up to 20 sets of methods, each set with a maximum of 99 paragraphs.
5. Maximum temperature to 350℃.
4. Fields of use Product
Hot Stage for microscope is widely used in medicine, chemical industry, synthetic fiber, biology, mineralogy, criminology and other fields.
5. Product qualification
Yuke Product has obtained CE certification, TART certification, ISO quality management system certification, more than 10 software copyrights and multiple patents to ensure that each instrument has stable performance and excellent quality.
