Chemical Titrator
LIST

Automatic potentiometric titrator

YK-T5

Product Category: Potentiometric titrator

Automatic Potentiometric Titrator is a high-precision electrochemical analysis instrument for volumetric analysis using potentiometric titration method. It adopts modular design and consists of volumetric titration device, control device and testing device.


Products Detail Technical Parameter Feature And Application Fields Of Use Details Download

1. Product introduction

Automatic Potentiometric Titratorcan carry out acid-base titration, REDOX, precipitation and complexation titration. The instrument has the functions of constant titration, micro titration, end-point setting titration, volume setting titration and mode titration. Users can also build their own special titration methods according to their actual needs.


2. Product parameter





Titration device





Volumetric titration unit

Titration analysis repeatability

0.2%

Allowable error of titration capacity

15ml burette:±0.025ml;

25ml burette: ±0.035ml

Burette resolution

15ml burette: 1/20000;

25ml burette: 1/10000

Titration volume accuracy

0.0001ml

Drive resolution

1/30000

Electronic unit repeatability error

≤0.2mV





Measuring device

Potentiometric Titration Module

Measuring range

(-1999.99-1999.99)mV,

(0.000-14.000) pH

Resolution

0.01mV, 0.001pH

Maximum possible error

0.2 mV, 0.02pH

Temperature compensation

Measuring range

(0-100.0)℃

Resolution

0.1℃

Basic error

±0.2℃

Number used for titration

2 pcs (15mL / 25mL )

Titration cup capacity

100mL

Isometric titration

YES

Integrated burette

YES

Used to stir samples

NO

PH correction

YES

Set end mode

YES

MV / PH measuring electrode interface

YES

Reference electrode interface

YES

PT1000 temperature electrode interface

YES

Host USB interface

YES

Stirrer interface

YES

Output Interface

Printer

Screen display

8 inch TFT touch color screen

Power supply

110-240V, 50/60 Hz

Weight

7.6kg


3. Product feature and application

1. Automatic sample injection, pipeline cleaning, automatic test;

2. 8 inch color touch screen, easy to operate and display titration curve and measurement results;

3. Support acid-base, REDOX, precipitation, complexation, non-aqueous titration and other titration methods;

4. Imported solenoid valve, PTFE corrosion-resistant burette, high-power magnetic stirring;

5. High precision closed-loop control to ensure accurate titration;

6. High precision burette accurate to 0.003mm;

7. Comply with GLP GMP certification; Support direct data printing.


4. Fields of use

Automatic potential titrator belongs to the laboratory general basic equipment, the use is very wide, can be used in food, drug testing, disease control, commodity inspection, water treatment, petroleum, chemical, Marine, electric power, environmental protection, new energy, teaching, scientific research and other related fields.


5. Product qualification

Yuke Automatic Potentiometric Titrator  has obtained CE certification, TART certification, ISO quality management system certification, more than 10 software copyrights and multiple patents to ensure that each instrument has stable performance and excellent quality.
